PPC-03001

7“Capacitive Touch Panel Pc Intel® Elkhart Lake Celeron J6412 with Fanless Design

Features :

7" true color LED display with 1024*600 resolution and a backlight service life of up to 50000 Hours.
The front panel is IP65 rated to prevent dust and splashing water droplets from entering the display.
Ultra-thin design, save cabinet space, shock, and vibration resistance.
9~36v voltage DC power input, meet the industrial field power supply.
High-precision capacitive screen, with many application characteristics in industrial sites
Both panels embedded and standard VESA mounting are supported, allowing users to flexibly choose the installation method.

7“Capacitive Touch Panel Pc Intel® Elkhart Lake Celeron J6412 with Fanless Design

PPC-03001
LCD DISPLAY	7”
CPU	Intel® Elkhart Lake Celeron J6412 Quad Core 2.6 GHz CPU
RAM	1*DDR4 SODIMM memory slot max 32GB
MAX. RESOLUTION	1280 x 800
STORAGE	1* M.2 SATA, 1 x SATA
NETWORK PORT	2 x Intel 2.5Gigabit Ethernet
AUDIO	RTLALC662 audio controller, LINE-out port
USB	2 * USB 3.0 port, 2 * USB 2.0
SERIAL PORT	1 x RS232 COM, 2 x RS232 /422/485
BRIGHTNESS	500cd/m2
DISPLAY	7” TFT LED
CONTRAST	700:1
MAXIMUM COLOR	16.7M
TYPES	High precision capacitive
CLICK LIFE	250 grams of strength, 50 million times
RESPONSE TIME	<5ms
TRANSMITTANCE	above 85%
HIGH TEMPERATURE TEST	85℃/1000hr
CONSTANT TEMPERATURE AND HUMIDITY TEST	85℃/90%RH/1000hrs
INSTALLATION METHOD	Embedded in panel, VESA mountable with bracket
POWER INPUT	9~ 36v DC power supply
DIMENSION	225.3W x 166.8D x 66.09H mm
PANEL CABINET	Aluminium profile face frame Abrasive back shell
OPERATING TEMPERATURE	-20°C to +60°C
STORAGE TEMPERATURE	-20℃～70℃
CERTIFICATION	CE, FCC, RoHS
WARRANTY	1 Year
