PPC-02009
PPC-02009
15“ Capacitive Touch Panel Pc i5-7th Gen with Fanless Design
Features :
- 15" true color LED, resolution 1024X768 backlight service life up to 30000 hours.
- 9v ~ 36v voltage DC power input, to meet the industrial field power supply.
- The ultra-thin design saves cabinet space and is resistant to shock and vibration.
- And it has many industrial site application features, while supporting panel embedded and standard VESA installation, users can flexibly choose the installation method.
Specification
15“ Capacitive Touch Panel Pc i5-7th Gen with Fanless Design
| PPC-02009 | |
|---|---|
|
LCD DISPLAY |
15’’ |
|
CPU |
Intel Core i5-7200U Processor 2Core 4 thread processor, TDP 15W |
|
RAM |
Support DDR3 SO-DIMM 2400MHz |
|
MAX. RESOLUTION |
1024 x 768 |
|
STORAGE |
1 x M-SATA/ 1* SATA |
|
NETWORK PORT |
2 * Rj45 |
|
AUDIO |
1 x Line-out/MIC IN |
|
USB |
4* USB 3.0 |
|
BRIGHTNESS |
350cd/m2 |
|
COM PORT |
6x RS232/2 x (422/485) |
|
MAXIMUM COLOR |
16M |
|
DISPLAY PORTS |
1x HDMI |
|
CONTRAST |
800:1 |
|
TOUCH |
Capacitive |
|
OS SUPPORT |
Windows / Linux |
|
INSTALLATION METHOD |
Embedded, with support for VESA installation, Desktop, Wall-Mounted |
|
POWER INPUT |
9V ~ 36V DC power supply |
|
DISPLAY DIMENSION |
370mm x 290mm x 48mm |
|
IP RATINGS |
IP65 |
|
OPERATING TEMPERATURE |
-20℃～60℃ |
|
STORAGE TEMPERATURE |
-30℃～80℃ |
|
CERTIFICATIONS |
CE, FCC |
|
WARRANTY |
1 Year |
