ICOM-16014
12 Port Managed Industrial Gigabit POE Ethernet Switch
Features :
- 8*10/100/1000Base-T copper ports + 4*1000Base-X SFP ports
- 8*PoE+, compatible with IEEE 802.3af/at standards
- The power supply of the single port is up to 30W, total PoE output power is up to 150W
- Supports detect the PoE mode of the PDs and perform intelligent management such as restarting the PD
- Support X-Ring private rings including single-ring, intersecting-ring, dual homing ring
Specification
| ICOM-16014 | |
|---|---|
|
Business Ports
|
8 * 10/100/1000Mbps RJ45 PoE/PoE+ copper ports, Full/half duplex mode, Auto MDI/MDI-X connection, 4* 1000Base-X SFP ports |
|
Debug
Interface |
1*RJ45 console port |
|
LED Indicator |
Power: PW1, PW2, System: RUN, SFP ports: LINK/ACT, Copper ports: ACT, PoE/PoE+: PoE |
|
Digital Input |
1xDigital input
Wet Contact: -30 to +3 V for State 0, +13 to +30 V for State 1 Max input current: 8mA
Dry Contact: Logic Level 0-Open; Logic Level 1-Close to GND
|
|
Alarm Contact |
1x Relay output, current capacity, 1A/24VDC |
|
Ethernet Standards |
IEEE802.3u-100BaseTX, IEEE802.3ab-1000BaseT, IEEE802.3x-Flow Control,
IEEE802.3z-1000BaseX, IEEE 802.1AB-Link Layer Discovery Protocol (LLDP), IEEE802.1D-Spanning Tree Protocol, IEEE802.1w-Rapid Spanning Tree Protocol, IEEE802.1Q -VLAN Tagging, IEEE802.1p -Class of Service
|
|
POE Standard |
IEEE802.3 af, IEEE802.3at |
|
POE Power |
Max. 30W/[email protected], Max. 15W/[email protected], Total PoE Budget: Max. 150W |
|
POE Ports |
Port No.1~8 supports PoE/PoE+, automatically detects the standards of devices like
IEEE802.3af or IEEE802.3at
|
|
Management |
Supports console, and WEB management, Supports SNMP v1/v2c centralized management, RMON port mirroring, QoS, LLDP, DHCP Server, DHCP Client, Document management, Port statistics, SNTP time management |
|
Redundancy
Technology |
Supports STP/RSTP, ERPS |
|
Multicast |
IGMP snooping, GRAP, static multicast |
|
Security |
User privilege classification, ACL, 802.1X authentication, port alarm, power alarm, storm control, SSHD deployment, Telnet deployment, HTTPS deployment |
|
Input Voltage |
DC48V, Phoenix Terminal |
|
Operating Temperature
|
-40~+80°C(-40~176°F) |
|
Storage
Temperature
|
-40~+85°C(-40~185°F) |
|
IP Rating |
IP40, aluminum shell |
|
Dimensions |
135 mm* 135mm * 60mm |
|
Installation |
DIN-rail mounting, Wall Mounting |
|
EMI |
FCC Part 15 Subpart B Class A, EN 55022 Class A |
|
EMS |
IEC(EN)61000-4-2(ESD): Contact discharge: ±8kV, Air discharge: ±12kV,
IEC(EN)61000-4-3(RS): 10V/m(80~1000MHz),
IEC(EN)61000-4-4(EFT): Ethernet Port: ±4kV CM//±2kV DM;
IEC(EN)61000-4-5(Surge): Ethernet Port: ±4kV CM//±2kV DM;
IEC(EN)61000-4-6(Conducted RF immunity) 3V(10kHz~150kHz),10V(150kHz~80MHz), IEC(EN)61000-4-16(Conducted common mode disturbances immunity): 30V cont.
300V, 1s
IEC (EN )61000-4-8
|
|
Shock
|
IEC 60068-2-27 |
|
Vibration |
IEC 60068-2-6 |
|
Warranty |
3 years |
