SERVICE PORTS

24 * 10/100/1000Mbps RJ45 copper ports, Full/half duplex mode, Auto MDI/MDI X connection, auto detects direct cable and crossover cable, 4 * 10G SFP+ fiber ports, support rate: 1G/2.5G/10G

MANAGEMENT PORT

1* Console

RESET KEY

1* reset key to restore factory default setting

ETHERNET STANDARDS

IEEE802.3-10BaseT Ethernet, IEEE802.3u-Fast Ethernet, IEEE802.3ab-Gigabit Ethernet Standard, IEEE802.3z- Gigabit Ethernet over Optical Fiber 3 / 5, IEEE802.3ae-10 Gigabit Ethernet Standard, IEEE 802.3ad-Link Aggregation Control Protocol (LACP), IEEE802.3x-Flow Control of Full Duplex Ethernet Data Link Layer, IEEE 802.3az-EEE (Energy Efficient Ethernet) Standard

SYSTEM MAINTENANCE

Supports uploading/downloading of the config file, uploading of the upgrading package, restoring factory default setting by WEB, system log Supports Ping, tracert, and network cable detection, management by WEB interface (supports http and https protocols), CLI management, Telnet remote management, SSH 2.0, SNMP network management, RMON, LLDP

VLAN

Supports up to 4096 VLANs, VLAN with 802.1Q standard, QinQ, Voice VLAN, MAC VLAN, IP VLAN

SWITCHING FUNCTIONS

Supports Storm Suppression, Port Aggregation, Port Mirroring, Port Flow Control

IP ROUTING

Supports port-based input/output bandwidth management, static routing, RIP, RIPng, OSFP, OSPFv3 dynamic routing, VRRP (virtual routing redundancy protocol)

LOOP PROTECTION

Support loop detection/loop avoidance

RING NETWORK PROTOCOL

Supports ERPS industrial ring network protocol

MULTICAST

Supports MLD Snooping (Multicast Listener Discovery Snooping), IGMP snooping 4 / 5

SECURITY FEATURES

Supports IP ACL, MAC ACL, Vlan ACL, supports ACL function based on Layer 3 and 4, port-based IP + MAC binding, IP Source Guard, ARP Detection, IEEE 802.1x authentication, Radius authentication

CLOCK PROTOCOL

Supports NTP, PTP（1588v2）

DHCP

Supports DHCP Client, DHCP Server, DHCP Snooping, DHCP Relay

INPUT VOLTAGE

AC110-240V

OVER CURRENT PROTECTION

Current limit 4.0A

TRANSMISSION MODE

Store-and-forward

MAC TABLE SIZE

32K, supports auto updating, bidirectional learning

PACKET FORWARDING RATE

406Mpps

SWITCHING LATENCY

1.2Tbps

POWER

<30W

WORKING HUMIDITY

10%~90% (non-condensing)

STORAGE HUMIDITY

5%~95% (non-condensing)

IP RATING

IP40, aluminum shell

DIMENSIONS

442*194*44mm

MTBF

300,000 hours

OPERATING TEMP

-40~+80°C(-40~180°F)

STORAGE TEMP

-40~+85°C(-40~185°F)

WARRANTY

3 years
