PROCESSOR

12th/13th/14th Gen Intel® Core™ i3/i5/i7/i9, Celeron® processor

CHIPSET

Intel® Q670E Chipset

MEMORY

Non-ECC DDR5 4800MHz, 2x SO-DIMM, up to 64GB

DISPLAY

1x HDMI 2.0, 5x DisplayPort

ETHERNET

2x 2.5GbE (Intel® I225-LM)

SERIAL PORTS

1x RS-232/422/485, 1x RS-232

USB

[Front] 1x USB 3.2 gen 2 Type A [Rear] 2x USB 3.2 Gen 2 Type A, 4x USB 3.2 Gen 1 Type A, 1x USB 3.2 Gen1 Type C

M.2

1x M.2 E-key supporting 1630 or 2230 for Wi-Fi/BT module 1x M.2 M-key supporting 2242 or 2280 for PCIe/SATA for storage 1x M.2 M-key supporting 2242 or 2280 for PCIe Gen 4 x4 for NVMe & frame grabber

SATA/PCIe

2x 2.5″ SATA 6Gb/s external drive bays, 1x M.2 2242/2280 M key support SATA/PCIe gen 3 x 3 to support storge, 1x M.2 2242/2280 M key support PCIe gen 4 x 4 to support storge

DIGITAL IO

1x DI/DO with 4 in, 4 out

AUDIO

Default: Mic in & line out, Option: L/R speaker-out (2W + 2W), Mic-in

TPM 2.0

Default: TPM, Optional: w/o TPM

VIBRATION

Operating vibration: 2Grms, 5-500Hz, 3 axes, Package (NON-OP) vibration: 3.44Grms, 10-1000Hz, 3 axes (W/MXM, W/SSD)

MOUNTING

Optional wall-mount bracket

DIMENSIONS

280 x 198 x 98 mm (W x D x H, without foot pads)

DC INPUT

DC 24 input (Molex DC-in jack)

AC INPUT

450W (24V/18.75A) AC/DC Medical grade adapter

OPERATING TEMPERATURE

0°C to 40°C

STORAGE TEMPERATURE

-20°C to 70°C

HUMIDITY

5% to 95%, non-condensing

EMC

EN55032/35, CE, FCC

SAFETY

UL/cUL and CB (62368-1:2014)

MEDICAL GRADE

Compliant with IEC 60601-1:2005 + A1:2012 + A2:2020 (3.2 edition) / IEC 60601-1-2:2014 + A1:2020 (4.1 edition)

WARRANTY

2 Years
