FORM FACTOR

Micro ATX (22.6cm x 18.5cm)

CPU

Intel® i7-14700 20 Core Processor

CHIPSET

Intel® H610 chipset

BIOS

AMI Flash ROM

RAM

DDR4 4800MHz, 2 * UDIMM, 64GB (default 32GB RAM)

DISPLAY GRAPHICS

by CPU

ETHERNET

1 * RJ 45, 10/100/1000/2500 Mbps

AUDIO

1 (Line-In, Line-Out, MIC)

HDMI

1

PCIe

1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16

PCI

1* PCI

M.2

1 x M.2 connector (Socket 3, M key, type 2280/2260 PCIe 3.0 x4/x2 SSD support)

CLEAR CMOS

1

SATA

2

USB

2 X USB 3.2, 4 X, USB 2.0, 1 * USB 3.0 & 1 * USB 2.0(Internal)

FRONT PANEL

1

FRONT PANEL AUDIO

1

POWER ON

AT/ATX Supported

TPM

1

INPUT PWR

24 pin/8 pin ATX PWR Connector

OPERATING TEMP

0°C – 60°C

STORAGE TEMP

-20°C – 70°C

CERTIFICATIONS

CE, FCC, RoHS, REACH

WARRANTY

2 Years
