Form Factor

ATX (248.84* 246.84mm)

CPU

Intel® LGA1700 Socket Core i3, i5, i7 12th / 13th Generation Processor.

Chipset

W680 chipset

BIOS

AMI 128M Flash ROM BIOS

RAM

4 * DDR5 long-DIMM 4800/5600MT/s up to 128GB

Display Graphics

by CPU

VGA

1* VGA (Max. Resolution: 1920×1080@60Hz)

HDMI

1* HDMI (Max Resolution: 4096×2160@24Hz)

DP

1* DP (Max Resolution: 1920×1080@60Hz)

MULTIPLE DISPLAY

Dual Display

Ethernet

2* Intel 2.5 GbE (2* i226)

Audio

1, Line-Out + MIC +Line-in 1, Line-Out + MIC

M.2

1 x M.2 2242/2280, support PCI-E 4.0 x4 1xM.2 2280，support PCIE3.0 x 4

PCIe

2* PCIe 4.0 x4, 1* PCIe x16, 1* PCIe 3.0 x4

Storage

8 SATA3 6Gb/s ports, supporting Raid 0, 1, 5, 10. 1* M.2 M-key (2242/2280), 1 * M.2(2242)

USB

5* USB 3.0, 2* USB 2.0, 1 * USB 3.0 Via Header

Serial

2, RS232

Panel

1, PWR On +Reset +PWR_LED +HDD_LED

PARALLEL

1

IPMI

1 x IPMI management interface

TPM

Optional

CHASSIS INTRUSION

1

Audio Header

1

AT mode

1

Input PWR

24 pin/8 pin ATX PWR Connector

Operating Temp

0°C – 35°C

Storage Temp

-40°C – 75°C

Certifications

CE, FCC, RoHS, REACH

Warranty

2 Years
