Form Factor

ATX(305 * 244mm)

CPU

Intel® Core™ Ultra Processors (Series 2), LGA1851 Support MAX CPU TDP: 125W

Chipset

Intel® Q870, TDP 6W

BIOS

AMI UEFI BIOS

RAM

4, DDR5 No ECC U-DIMM upto 192GB

Display Graphics

by CPU

VGA

1, VGA, max 1920*1200@60Hz

HDMI

1, HDMI, max 4096*2160@60Hz

DP

1, DP++, max 4096*2160@60Hz

Ethernet

1, Intel® i219V GbE Ethernet Controller 1, Intel® i210AT GbE Ethernet Controller

Audio

1, Line-Out + MIC +Line-in 1, Line-Out + MIC 1, SPDIF Out

PCI

1*PCI

PCIe

1* PCIe x16 &4 * PCIe X 4 slots

M.2

1, M.2 E-Key 2230, PCIe + USB2.0, support WIFI + Bluetooth 1, M.2 M-Key 2280, PCIE x4/SATA, support NVMe/SATA SSD, Auto detect

Storage

4 * SATA

USB

4, USB3.2 5Gbps 2, USB3.2 10Gbps, 7 * USB2.0

Serial

6, RS232, COM1-6

Panel

1, PWR On +Reset +PWR_LED +HDD_LED

TPM

TPM 2.0(Optional)

WATCHDOG

System reset, programmable 1-255 sec or min

GPIO

8, 4* GPI+ 4* GPO, non-isolated 5V

SMBUS/ I2C

1

Audio Header

1

AT mode

1

Input PWR

24 pin/8 pin ATX PWR Connector

Operating Temp

0°C – 60°C

Storage Temp

-20°C – 75°C

Certifications

CE, FCC, RoHS, REACH

Warranty

2 Years
