Form Factor

ATX (305 * 217mm)

CPU

Intel® LGA1151 Socket Core i3, i5, i7 Pentium Processor

Chipset

H310 Chipset

BIOS

AMI UEFI BIOS

RAM

2 * DDR4 2400MHz Upto 32GB

Display Graphics

by CPU

VGA

1* VGA (Max. Resolution: 1920×1080@60Hz

HDMI

1* HDMI (Max Resolution: 4096×2160@24Hz

DVI

1* DVI-D (Max Resolution: 1920×1080@60Hz

eDP

1*eDP (Max Resolution: 1920×1080@60Hz

MULTIPLE DISPLAY

Dual Display

Ethernet

2 * RJ45

Audio

1, Line-Out + MIC +Line-in 1, Line-Out + MIC 1, SPDIF Out

PCI

4*PCI

PCIe

1* PCIe x16 &1 * PCIe X 4 & 1 * PCIe X 1

Mini-Pcie

1* Wi-Fi/3G/4G

Storage

4 * SATA

USB

4 *USB3.0, 2* USB2.0, 3*USB 2.0

Serial

6, RS232, COM1-6

Panel

1, PWR On +Reset +PWR_LED +HDD_LED

PS/2

1

WATCHDOG

System reset, programmable 1-255 sec or min

CHASSIS INTRUSION

1

Audio Header

1

AT mode

1

Input PWR

24 pin/8 pin ATX PWR Connector

Operating Temp

0°C – 60°C

Storage Temp

-20°C – 75°C

Certifications

CE, FCC, RoHS, REACH

Warranty

2 Years
