CPU

Intel® Core™ Series 2 Processors and 14/13/12th Gen Intel® Core™ Processors, LGA1700, up to 65W

CHIPSET

Intel® H610 Chipset

MEMORY

2x 288-pin non-ECC U-DIMM sockets, Dual-channel DDR4 3200MHz, up to 64GB, OR up to 96GB

BIOS

BIOS AMI® UEFI BIOS, 256MB SPI Flash Memory

SERIAL PORTS

2x RS-232/485 by pin header, 4x RS-232 (COM1 by DB9/M, others via headers)

ETHERNET

1x Intel® I226-V, 1GbE 1x Intel® I219-V, 1GbE

SATA

3x SATA3.0 OR 4x SATA3.0

USB

4x USB 3.0 (rear I/O), 2x USB 2.0 (rear I/O), 4x USB 2.0 (via headers, 1x colay with vertical type A)

DP

1* DP (Max Resolution: 1920×1080@60Hz)

EXPANSION SLOTS

3x PCI 1x PCIe Gen4 x16, 3x PCIe x4 (Support PCIe Gen3 x2 signal) 1x M.2 2242/2280 M-key (Support SATA SSD)

DIO

8-bit GPIO

PS/2

1x PS/2 keyboard & mouse pin header

MULTIPLE DISPLAY

Three Displays

DVI

1x DVI-D (DVI-I), max resolution up to 1920×1200 @ 60Hz

HDMI

1x HDMI 1.4b, max resolution up to 4096×2160 @ 30Hz

VGA

1x VGA, max resolution up to 1920×1200 @ 60Hz

AUDIO

Realtek ALC897, 1x Line-out, 1x Line-in, and 1x Mic-in connector (rear I/O)

OPERATING SYSTEM

Microsoft® Windows® 10/11 64-bit

OPERATING TEMPERATURE

0°C to 60°C

STORAGE TEMPERATURE

-20°C to 75°C

RELATIVE HUMIDITY

60°C @ 95% RH, Non-condensing

CERTIFICATION

CE & FCC Class A

Warranty

2 Years
