Dimension

174*128*78MM

CPU

Intel i7-8765U 1.80Ghz 4 Core 8 Thread Processor

CHIPSET

SOC

RAM

2*DDR4 SODIMM MAX 32GB

GRAPHICS

Integrated Intel® Iris™ Graphics 540, support DirectX 12 OpenGL 4.4, support

HDMI

1

VGA

1

ETHERNET

3*Intel® WGI211ATGigabit Ethernet, support Wake On LAN, PXE function

PS / 2

1

SATA

1 * SATA

M-SATA / M.2

1 * MSATA, 1*M.2 slot, support M.2 2260 / 2280 NVME PCIE standard SSD

AUDIO

1* Line out interface, 1* MIC interface

USB

4* USB3.0 interface,3*USB2.0

SERIAL PORT

6* RS232 COM port, all support RS485

SWITCH

1* Power switch, 1* reset switch

LED

1*H.LED

PHONEIX

1*3pin Phoenix terminal

WATCHDOG

Support hardware reset function (L256, 0~255 second

MINI-PCIE

1* Mini PCIE slot, support Wi-Fi / 4G module

GPIO

1* 12pin, support 4-in 4-out GPIO，switch，5V

SIM

1* SIM card slot

AC LOSS

1

POWER TYPE

External Power Adapter

INPUT POWER

DC 9V~36V wide voltage input

WATT

36W~180W

POWER CONSUMPTION

>60W

OPERATING TEMP

-10℃～60℃

STORAGE TEMP

-20℃～70℃

HUMIDITY

5%-95% relative humidity, non-condensing

VIBRATION

0.5g rms / 5-500HZ / random / operating

CERTIFICATEION

CE, FCC

ACESSORIES

1 * Power adaptor, 1* HDD Clamp.

WARRANTY

2 Years
