PROCESSOR

Intel® Core™ Ultra Processor

VIDEO

Mali-G52 1-Core-2EE

MEMORY

2x DDR5 SO-DIMMs 5600MHz, up to 96 GB, non-ECC

NUMBER OF DISPLAYS

4 (HDMI, DP, Type-C, LVDS/eDP)

PCIe

1x M.2 2280 M Key (PCIex4) 1x M.2 2230 E Key (PCIe Gen 4×1, USB) 1x M.2 3042 B-key (USB3.0/2.0, PCIex1

M.2

M.2 Socket 2 Key B for LTE module + micro-SIM card slot on-board – Optional on-board M.2 1216 module WLAN 802.11 a/b/g/n ac + BT 5.0, M.2 Socket 2 Key M for AI accelerator modules

STORAGE

eMMC 5.1 drive soldered on-board, up to 64GB (first boot device) microSD slot (second boot device) I2C flash QSPI flash (factory option)

AUDIO

Realtek ALC888S 1x line-in, 1x line-out, MIC-in through 30pin header

ETHERNET

2x Intel® I226V, 2.5Gps / 1Gbps/ 100Mbps / 10Mbps, Gbe Port

LAN

2x 2-lanes MIPI-CSI camera connector or 1x 4-lanes

BIOS

AMI 128Mb Flash ROM

HDMI

1 * 4k x 2k @60Hz

USB

2x USB 3.2 Gen 2×1 ports (10Gbps) (rear I/O) 2x USB 2.0 through 30pin header, 1x USB 2.0 via headers, 1x USB TYPE-C (USB 3.2, DP, Power delivery 5V, 3A)

DP

1x DP1.4

COM

2x RS-232/422/485 pin headers

SERIAL ATA

1x SATA 6Gb/s ports w/ 5V SATA power

SIM

1

POWER INPUT

+12-24V DC-in

SMBUS/ I2C

1

SPI

1

DISPLAY

eDP 4K @60Hz, LVDS 1080P

eSPI

1

OS SUPPORT

Win10/ Win11 24H2 LTSC Ubuntu 22.04LTS (support by project)

POWER SUPPLY

12V-24V connector type: 2×2 connector + DC JACK co-la

CERTIFICATIONS

CE & FCC Class B

OPERATING TEMPERATURE

0°C – 60°C

STORAGE TEMPERATURE

-40°C to 85°C

WARRANTY

2 Years
