CPU

Intel® Celeron® Processor

CHIPSET

SoC (System-On-Chip)

USB

1x USB 3.0 port on rear I/O, 2x USB 2.0 ports on board with pitch 2.0 header

RAM

Up to 8GB DDR3L 1333/1600/1866 MH/z SDRAM on one 204-pin SO-DIMM socket

GRAPHIC CONTROLLER

Intel® Gen 9 Graphics supports DirectX 12, OpenGL 4.2 / OpenCL 2.0, Video decode HW acceleration support for H.264, H.265, MPEG2, VC-1/WMV9, JPEG, VP8, and VP9

LVDS

LVDS dual channel 24bit LVDS on board connector, up to 1920×1200

HDMI

HDMI on board connector, resolution up to 3840 x2160

STORAGE

One SATA III port

NETWORK

Single Intel® I211AT GbE controller 1x RJ45 connectors on rear I/O

MINI PCIE

One mini-PCIe socket (support mSATA)

DIMENSIONS

100×72 mm

AUDIO

High-Definition Audio integrated in Intel SoC. Supports Line-out on-board pin header

WATCHDOG TIMER

Programmable watchdog timer, time out period from 1 sec to 255 secs

GPIO

GPIO 8-bit configurable controlled by embedded controller

OS SUPPORT

Windows 10 IOT Enterprise, Windows 10 IOT Core, Linux

POWER INPUT

DC 12V input

OPERATING TEMPERATURE

0°C to +60°C

STORAGE TEMPERATURE

-40°C to +85°C

BUS INTERFACE

1x RS-232/422/485 with on board pin header, 1x RS-232 with on board pin header

CERTIFICATIONS

CE, FCC

WARRANTY

1 Year
