CPU

7th gen Intel® Core™ i7/i5/i3 and Celeron® processor onboard

CHIPSET

SoC integrated

BIOS

AMI

RAM

1 x 260-pin DDR4-2133 SO-DIMM, up to 16GB

SSD

1 x M.2 Key B 2242 (SATA, USB 2.0, optional PCIe x2)

ETHERNET

1 x 10/100/1000 Mbps Ethernet with Intel® I219-LM; supports Wake-on-LAN, PXE Boot ROM 1 x 10/100/1000 Mbps Ethernet with Intel® I210-AT; supports Wake-on-LAN, PXE Boot ROM

DISPLAY

Intel® HD Graphics

LVDS

1 x LVDS; 18/24-bit single/dual channel

DP

1 x DisplayPort++

M.2

1 x M.2 Key E 2230 (PCIe x1/USB 2.0)

SATA

Refer to ordering information

USB

2 x USB 2.0 2 x USB 3.0

SERIAL

2 x RS-232/422/485

SMBUS

Yes; compatible with I2 C

HARDWARE MONITORING

Detect CPU/system temperature, voltage and fan speed

DIGITAL I/O

4-channel in/out programmable

DIMENSIONS

100 x 72 mm

WATCHDOG TIMER

65536 levels, 0 to 65535 sec

AUDIO

Refer to ordering information

POWER INPUT

2 x 2-pin connector +12V DC-in only AT Auto Power On function supported

RELATIVE HUMIDITY

10% to 95% relative humidity, non-condensing

OPERATING TEMPERATURE

-20°C to +60°C (-4°F to 140°F)

CERTIFICATIONS

CE, FCC

WARRANTY

1 Year
