CPU

Intel® Core™ i7/i5/i3 8th gen and Celeron® processor onboard

BIOS

AMI

RAM

1 x 260-pin DDR4-2400 SO-DIMM, up to 32GB

SSD

64GB/128GB eMMC (optional)

ETHERNET

1 x 10/100/1000 Mbps Ethernet with Intel® I219-LM supporting Wake-on-LAN, PXE Boot ROM, 1 x 10/100/1000 Mbps Ethernet with Intel® I210-AT supporting Wake-on-LAN, PXE Boot ROM

DISPLAY

Intel® HD Graphics

LVDS

1 x LVDS; 18/24-bit single/dual channel

HDMI

1 x HDMI 1.4

DP

1 x DisplayPort++

M.2

1 x M.2 Key E 2230 (PCIe x1/USB 2.0)

SATA

1 x SATA-3

USB

2 x USB 2.0 2 x USB 3.2 Gen1

SERIAL

2 x RS-232/422/485

SMBUS

Yes; compatible with I2 C

DIGITAL I/O

4-channel in/out programmable

DIMENSIONS

152.5 mm (6”) (W) x 107.5 mm (4.23”) (D) x 50mm (1.97”) (H)

WATCHDOG TIMER

65536 levels, 0 to 65535 sec

POWER INPUT

2 x 2-pin +12V DC-in connectors with AT auto power on

POWER REQUIREMENTS

Intel® Core™ i7-8665UE @1.7 GHz 16GB DDR4, min. RMS. [email protected]

RELATIVE HUMIDITY

10% to 95% relative humidity, non-condensing

OPERATING TEMPERATURE

-20°C to +60°C (-4°F to 140°F)

CERTIFICATIONS

CE, FCC

WARRANTY

1 Year
