CPU

Intel® processor N97/Core™ i3-N305 processor

CHIPSET

SoC integrated

BIOS

AMI

USB

2 x USB 2.0, 2 x USB 3.2

RAM

8GB LPDDR5 onboard (16GB optional)

ETHERNET

2 x 10/100/1000/2500 Mbps Ethernet (Intel® I225)

LVDS

1

HDMI

1

M.2

1 x M.2 Key E 2230 (PCIe x1/USB 2.0) 1 x M.2 Key B 3042/3052 (PCIe x1/USB 3.2), optional

STORAGE

1 x M.2 Key B 2242 (PCIe x2/USB 2.0) 1 x PCIe NVMe SSD onboard, up to 512GB (optional)

DIGITAL I/O

4-channel in/out programmable

DIMENSIONS

100 x 72 mm

AUDIO

HD Audio link via pin header

TPM

TPM 2.0

BATTERY

Lithium 3V/220 mAh

WATCHDOG TIMER

255 levels, 0 to 255 sec

HARDWARE MONITORING

Yes

POWER INPUT

2 x 2-pin connector, +12V DC-in only, AT auto power on function supported

RELATIVE HUMIDITY

10% to 95% relative humidity, non-condensing

OPERATING TEMPERATURE

-20°C to +70°C (-4°F to +140°F

CERTIFICATIONS

CE

WARRANTY

1 Year
