CPU

Intel® Apollo Lake SoC Processor

CHIPSET

SoC

BIOS

AMI SPI 128 Mbit

DIMENSIONS

PICO-ITX (3.9-in x 2.8-in, 9.0 cm x 7.1 cm)

RAM

1 x 204-pin SO-DIMM, DDR3L 1866 MHz, 8 GB

GRAPHICS

Intel® Gen9 Graphics DX 12

HDMI

HDMI 1.4b Max resolution up to 4096 x 2160@24Hz

STORAGE

1 x Full size with SATA3 and USB 2.0, 1 x SATA3 (6Gb/s)

LVDS

Dual channel 24 bit up to 1920×1200@60Hz

MULTIDISPLAY

Dual Display

MINI PCIe

1 x Full size with USB 2.0

M.2

1 x Key E (2230) with PCIe x1 and shared USB 2.0 for Wireless

EXPANSION SLOT

1, (HDMI or DP, 1 x USB3.0, 1 x USB2.0, 3 x PCIe x1, Line out, LPC bus , SMBus)

AUDIO

Realtek ALC897, High Definition Audio. Line-out, Mic-in

ETHERNET

1 x RJ-45, Intel® I210IT with 10/ 100/1000 Mbps

USB

1 x USB 3.1 Gen1, 1 x USB 2.0 (2 x 2.54 pitch header)

COM

1 x COM1 (RS-232/422/485), 1 x COM2 (RS232)

GPIO

4 x GPI + 4 x GPO

LVDS

1 (Connector with LVDS/eDP signal, switch by BIOS)

INPUT PWR

12V DC-In

WATCHDOG TIMER

256 Segments, 0, 1, 2, …255sec

SATA PWR OUTPUT

1

POWER ON

AT/ATX supported

OPERATING HUMIDITY

5% ~ 90%

OPERATING TEMP

0ºC ~ 60ºC

STORAGE TEMP

-40° C ~ 85° C

STORAGE HUMIDITY

5% ~ 90%

CERTIFICATIONS

CE, FCC

WARRANTY

1 Year
