CPU

Intel® Alder Lake-N SoC Processors

BIOS

AMI SPI 256 Mbit

DIMENSIONS

Pico-ITX (3.9-in x 2.8-in x 0.76-in, 10 cm x 7.2 cm x 1.93 cm)

RAM

1 x 262-pin SO-DIMM, DDR5 4800 MHz, 32 GB

GRAPHICS

Intel® UHD Graphics

HDMI

HDMI 2.0b, Max resolution up to 4096 x 2160@60Hz

STORAGE

1 x M.2 (Key M, 2242/2280) with PCIe Gen3 x1 or SATA3 and USB 2.0 for SSD

LVDS

Dual channel 24 bit up to 1920 x 1200@60Hz (Connector shared with eDP)

EDP

Max resolution up to 1920 x 1080@60Hz (Connector shared with LVDS)

MULTIDISPLAY

Triple display

M.2

1 x M.2 (Key E, 2230) with PCIe Gen3 x1 and USB 2.0 for Wirele

EXPANSION SLOT

1 (HDMI or DP, 1 x USB 3.2 Gen2, 1 x USB 2.0, 3 x PCIe x1)

AUDIO

Realtek ALC897 HD, High-Definition Audio. Line-in, Line-out, Mic-in

ETHERNET

Realtek RTL8125BG with 10/100/1000/2500 Mbps

USB

1 x USB 3.2 Gen2 (Type A), 2 x USB 2.0 (1×2.00 pitch header)

COM

COM1, COM3 (RS-232/422/485)

GPIO

4 x GPI, 4 x GPO

LVDS

1 (Connector with LVDS/eDP signal, switch by BIOS)

WATCHDOG TIMER

256 Segments, 0, 1, 2, …255sec

INPUT PWR

12V DC-In

POWER ON

AT/ATX supported

OPERATING HUMIDITY

5% ~ 90%

OPERATING TEMP

-20ºC ~ 70ºC

STORAGE TEMP

-40° C ~ 85° C

STORAGE HUMIDITY

5% ~ 90%

CERTIFICATIONS

CE, FCC

WARRANTY

1 Year
