DIMENSIONS

114.5×114.5x54mm

CPU

Onboard Intel Core Arrow Lake series 225H processor, TDP28W

BIOS

EFI

STORAGE

1*M.2 M-Key 2280 (NVMe PCIe 4.0 x4) 1*SATA3.0，2Pin 5V

RAM

2*DDR5 SO-DIMM，Max up to 96GB

DISPLAY

2*HDMI 2.1 interface, support 4K@60Hz, 2*Type-C interface, support DP 4K@60Hz and USB3.0

ETHERNET

2*LAN

M.2

1*M.2 E-Key (PCIe +USB2.0 protocol, WIFI/BT module)

AUDIO

1

USB

2*USB3.0, 1*USB2.0 pin header

SERIAL

1*RS232 pin header

FAN

1*4Pin PWM CPU FAN

POWER INPUT

DC 12-19V, 90W and above

OPERATING SYSTEM

Windows10, Windows11, Linux

WORKING HUMIDITY

0% ~ 90% relative humidity, non condensation

CERTIFICATIONS

CE, FCC

OPERATING TEMPERATURE

-40 ℃ ~ +85 ℃

STORAGE TEMPERATURE

-20 ℃ ~ +60 ℃

WARRANTY

2 Years
