DIMENSIONS

128X128X46mm

CPU

Integrated Intel J1900/I3 I5 I7 dual-core four-thread processor TDP 15W

CHIPSET

Based on Intel® Skylake-U SOC platform

GRAPHICS

Integrated Intel® UHD Graphics, support DirectX 12 Open GL 4.5,4k/60Hz

M.2

1* M.2 slot, support Wi-Fi module

RAM

2*DDR4 SODIMM memory slot, support 2133MHz memory, maximum support 32GB

HDMI

1*HDMI 2.0, 1*HDMI1.4

VGA

1*VGA interface (1920X1200@60Hz),

ETHERNET

2*Intel® WGI211AT Gigabit network card, support Wake on LAN, PXE function

SATA

1*2.5-inch hard drive expansion.

M.2

1* M.2 slot, support M.2 2280 NVME PCIEx4/SATA SSD auto detect

AUDIO

1* Line out，1* MIC, onboard ALC662 6 channel high fidelity audio controller

DISPLAY

Integrated Intel® Iris™ Graphics 540 supports DirectX 12 OpenGL 4.4, supports 4K

COM

2* RS232 DB9 COM port, support RS485/232 switchable, the 9th pin charged function

POWER INPUT

1* 12V power adapter port

POWER SWITCH

1* Power switch, 1* Reset switch,

AC LOSS

1*AC LOSS (Toggle switch when power on)

SIM

1* SIM slot (need install 3G/4G module)

USB

2* USB2.0，2* USB3.0

COM

2* RS232 DB9 serial interface, COM2 supports RS232/RS485 switch

DP

1* DP interface (4096X2304@60Hz)

PWR TYPE

External Power Adapter

INPUT PWR

DC 12v

SIM

1* SIM card slot, 3G/4G module application

CERTIFICATIONS

CE, FCC, RoHS

OPERATING TEMPERATURE

-10℃～60℃

STORAGE TEMPERATURE

-20℃～70℃

WARRANTY

2 Years
