DIMENSIONS

128mm*128mm*56.31mm

CPU

Integrated Intel Celeron i5-8265U QUAD-core Eight-thread processor TDP 15W

GRAPHICS

Integrated Intel® UHD Graphics, support DirectX 12 Open GL 4.5,4k/60Hz

MINI PCIE

1* Mini-PCIE slot, support 4G module

M.2

1* M.2 slot, support Wi-Fi module

RAM

2*DDR4 SODIMM memory slot, support dual-channel 2400MHz

HDMI

1*HDMI 2.0, 1*HDMI1.4

ETHERNET

2*Intel RTL8111H Gigabit LAN port, RJ 45, 10/100/1000 Mbps

SATA

1*2.5-inch hard drive expansion.

M.2

1* M.2 slot, support M.2 2280 NVME PCIEx4/SATA SSD auto detect

AUDIO

1* Line out，1* MIC, onboard ALC662 6 channel high fidelity audio controller

DISPLAY

1* HDMI2.0（4096×2304@60Hz, 1* HDMI 1.4(4096×2304@24Hz）

COM

2* RS232 DB9 COM port, support RS485/232 switchable, the 9th pin charged function

POWER INPUT

1* 12V power adapter port

POWER SWITCH

1* Power switch, 1* Reset switch,

SIM

1* SIM slot (need install 3G/4G module)

USB

2* USB2.0，2* USB3.0

AC LOSS

1*AC LOSS(auto power on switch）

PWR TYPE

External Power Adapter

INPUT PWR

DC 12v

CERTIFICATIONS

CE, FCC

OPERATING TEMPERATURE

-10℃～60℃

STORAGE TEMPERATURE

-20℃～70℃

WARRANTY

2 Years
