PROCESSOR

Intel Atom® Dual/Quad Core E3900 series Processor (up to 12W), 2MB Cache

BIOS

AMI UEFI BIOS

MEMORY

1x DDR3L 1866/1600 MT/s SO-DIMM up to 8GB

STORAGE DEVICES

1 x SATA III port, 1x mSATA socket (Choose either mSATA or mini-PCIe by BIOS), 1x Micro-SD socket

WATCHDOG TIMER

Programmable by embedded controller

HARDWARE MONITORING

Temperature (CPU & System), Voltage (CPU Vcore,12V, 5V, 3.3V, 1.35V)

EXPANSION INTERFACE

1x M.2 socket (E key), 1x full size mini-PCIe socket (Choose either mSATA or mini-PCIe by BIOS)

AUDIO

High-Definition Audio integrated in Intel® SoC, Realtek ALC892 HDA codec, Audio jack on rear I/O with Line-out and on-board pin header with Line-in, Line out, and Mic-in

ETHERNET

Dual Intel® I210IT GbE controller (E3950/ E3940 only), Dual RJ45 connectors on rear I/O (E3950/ E3940 only), Singal Intel® I210IT GbE controller and singal RJ45 (E3930 only)

SERIAL PORT

1x RS-232/422/485 on board connector (selected by bios)

USB

2x USB 3.0 ports on rear I/O, 2x USB 3.0 ports on board with header

GRAPHIC CONTROLLER

Intel® Gen 9 Graphics supports DirectX 12, OpenGL® 4.2 / OpenCL® 2.0, Video decode HW acceleration support for H.264, H.265, MPEG2, VC-1/WMV9, JPEG, VP8, and VP9

DISPLAY INTERFACE

Dual channel 24bit LVDS on board connector, up to 1920×1200, VGA: 1x DB-15 on board connector, up to 2560×1600, DP: 1x DP port on rear I/O, up to 4096x

DIMENSION

120mm(L) x 120mm(W); 4.72″(L) x 4.72″(W)

POWER SUPPLY

DC 12V input

OPERATING TEMPERATURE

-40°C~85°C

STORAGE TEMPERATURE

-40°C~85°C

RELATIVE HUMIDITY

5~95%, non-condensing

GPIO

8-bit configurable controlled by embedded controller

OTHERS

TPM 2.0 onboard

MTBF

Over 100,000 hours at 40°C

CERTIFICATIONS

CE, FCC Class B

WARRANTY

1 Year
