PROCESSOR

Intel Atom® dual/quad-core x6000E family SoC (up to 12W)

BIOS

AMI UEFI BIOS

MEMORY

DDR4 3200 MT/s Non-ECC SO-DIMM up to 32GB

STORAGE DEVICES

1x SATA III port, 1x mSATA socket (Choose either mSATA or mini-PCIe by BIOS), 1x Micro-SD socket

WATCHDOG TIMER

Programmable by embedded controller

HARDWARE MONITORING

System monitor (Voltage, Fan Speed and Temperature)

EXPANSION INTERFACE

1x M.2 Type E socket, 1x full size mini-PCIe socket (Choose either mSATA or mini-PCIe by BIOS)

AUDIO

High-Definition Audio integrated in Intel® SoC, Realtek ALC892 HDA codec, Audio jack on rear I/O with Line-out and on-board pin header with Line-in, Line-out, and Mic-in

ETHERNET

1x Intel® I226-IT 2.5GbE controller, 1x MaxLinear GPY215 2.5GbE PHY, 2x RJ45 connectors on rear

SERIAL PORT

1x RS-232/422/485 on board connector (selected by BIOS)

USB

2x USB 3.2 Gen 2 ports on rear I/O (10Gbps), 2x USB 3.2 Gen 2 ports on board with header (10Gbps)

GRAPHIC CONTROLLER

Intel® Gen 11 Graphics, Supports Real-time performance with Intel® Time Coordinated Computing (TCC) and Time Sensitive Networking (TSN)

DISPLAY INTERFACE

1x HDMI port on rear I/O, up to 4K resolution, 1x DP port on rear I/O, up to 4K resolution, 1x VGA on board connector

DIMENSION

120mm(L) x 120mm(W), 4.72″(L) x 4.72″(W)

POWER SUPPLY

DC 12V input

OPERATING TEMPERATURE

-40°C~85°C

STORAGE TEMPERATURE

-40°C~85°C

RELATIVE HUMIDITY

5~95%, non-condensing

GPIO

8-bit configurable controlled by embedded controller

OTHERS

TPM 2.0 onboard

CERTIFICATIONS

CE, FCC

WARRANTY

1 Year
