PROCESSOR

Intel Atom® x7000RE Series Processor (up to 12W)

BIOS

AMI UEFI BIOS

MEMORY

1x non-ECC DDR4 3200MT/s SO-DIMM up to 16GB, Support In-Band ECC

STORAGE DEVICES

1x SATA III, 1x M.2 B Key 2280(SATA III), 1x Micro SD socket

WATCHDOG TIMER

Programmable Watchdog Timer, time out period from 0.5 sec to 254.5 secs

HARDWARE MONITORING

System Monitor (Voltage, Fan speed, Temperature)

EXPANSION INTERFACE

1x M.2 E Key 2230, 1x M.2 B Key 3052/2280 (share with M.2 2280 SATAIII socket)

AUDIO

HDA controller integrated in Intel® SoC, Realtek ALC897 HDA codec, Audio jack on rear I/O (line-out), On board pin header (line-in, line-out, mic-in)

ETHERNET

2x Intel® 2.5GbE Controller (I226-IT), 2x RJ45 connectors on rear

SERIAL PORT

1x RS-232/422/485 port (selectable via BIOS)

USB

2x USB 3.2 Gen2 on rear I/O, 2x USB 3.2 Gen2 on board pin header (1x USB 3.2 Gen2 share with M.2 B key socket)

GRAPHIC CONTROLLER

Intel® UHD Graphics Gen12 with up to 32 EUs

DISPLAY INTERFACE

1x LVDS on board connector (Dual channel, 24bit, 1920×1200 @60Hz) 1x HDMI port on rear I/O (HDMI 2.0b, 4096×2160 @ 60Hz) 1x DP port on rear I/O (DP 1.4, 4096×2304 @ 60Hz)

DIMENSION

120mm(L) x 120mm(W), 4.72″(L) x 4.72″(W)

POWER SUPPLY

DC 12V input

OPERATING TEMPERATURE

0°C~60°C

STORAGE TEMPERATURE

-40°C~85°C

RELATIVE HUMIDITY

5~95%, non-condensing

MTBF

TBD

OTHERS

TPM 2.0 on board 8x GPIO Support real-time performance, Intel® TCC & TSN (selected SKUs)

CERTIFICATIONS

CE, FCC

WARRANTY

1 Year
