CPU

Support Intel Arrow Lake 15th gen Ultra 9 285H 16 cores, 16 threads

Size

170mm*170mm*25mm

BIOS

AMI BIOS

RAM

2*SODIMM, NB-DDR5memory, support 4800/5600MT/s memory, max support 96GB

LAN

1/2*RJ45_LAN interface, Supports Intel I219V+Realtek 8111H Gigabit Ethernet card

LAN

Intel 2.5G network (single and dual network optional)

M.2

1*M.2-WIFI interface, 1*M.2-4G/5G interface

HDMI

1*HDMI 2.0 interface, Support 4Kresolution 4096/3840*2160@60Hz

VGA

1*VGA, Support resolution 1920*1080@60Hz

DP

1*DP, Support DP++，4K resolution 4096/3840*2160@60H(OPTIONAL)

LVDS/EDP1

1*LVDS/EDP1pin, LVDS support 2K60Hz；EDP1 support 4K60Hz, 1*EDP2pin, support 4K resolution 4096/3840*2160@60Hz

USB

2*USB3.2, 2*USB2.0, 2*USB 2.0 (OPTIONAL)

AUDIO

Integrated Realtek ALC897HD digital audio decoder,6-channel high fidelity audio controller;

STORAGE

Supports PCIE4.0 signal, Key-M interface M.2 2280 hard drive. Standard SATA hard drive interface, support SATA3.0,

Switch

Switch, power light, hard disk light, restart pin

COM

6*COM, Supports standard RS232/RS422/RS485 optional

SIM

Supports SIM card, SIM card is required when using 5G/4G

CMOS

1 PS/2 pin heade1*CLR_CMOS pin rs, 2x4Pins, 2.54mm pitch

FAN

1*CPU_FAN pin, 1*SYS-FAN pin

GPIO

1*J_GPIO pin

OPERATING temperature

-10℃~60℃

OPERATING humidity

5%~95% relative humidity, no condensation

Watch Dog

Watch dog programming, supports hardware reset function (256 levels, 0-255 seconds)

Operating system

Supports Windows11, Windows10, Linux, etc

CERTIFICATIONS

CE, FCC

WARRANTY

2 YEARS
