PROCESSOR

Rockchip RK3568 4x Cortex®-A55 cores, up to 2.0GHz, 64-bit architecture, with Neural Processing Unit (NPU)

CHIPSET

SOC

VIDEO

Mali-G52 1-Core-2EE

MEMORY

Soldered down supporting DDR4-3200 up to 4GB total

MEMORY

Soldered down supporting DDR4-3200 up to 4GB total

M.2

M.2 Socket 2 Key B for LTE module + micro-SIM card slot on-board – Optional on-board M.2 1216 module WLAN 802.11 a/b/g/n ac + BT 5.0, M.2 Socket 2 Key M for AI accelerator modules

STORAGE

eMMC 5.1 drive soldered on-board, up to 64GB (first boot device) microSD slot (second boot device) I2C flash QSPI flash (factory option)

AUDIO

Line-out jack, TRRS combo audio jack (stereo mic in, stereo line out)

ETHERNET

2 * RJ-45 GbE LAN

LAN

2x 2-lanes MIPI-CSI camera connector or 1x 4-lanes

BIOS

AMI 128Mb Flash ROM

HDMI

1 * 4k x 2k @60Hz

USB

2 * USB 3.0, 1 * USB 2.0 port, 1 * USB Header for 2 * USB 2.0 ports

SIM

Micro SIM slot

POWER INPUT

+12-24V DC-in

SERIAL

2 * Serial headers (2 * RS232/422/485)

SMBUS/ I2C

1

SPI

1

DISPLAY

eDP 4K @60Hz, LVDS 1080P

CAN

2

GPIO

8-bit GPIO header or 4-bit GPIO, 8x GPIOs or 4x GPIOs + 4 ADC (factory configuration alternatives)

UART / JTAG

1x debug UART, 1x JTAG port, 2x 2 wire TTL UART ports on internal header

CERTIFICATIONS

CE, FCC, RoHS, ERP

OPERATING TEMPERATURE

0°C – 60°C -30°C ÷ +85°C (Extended version, with Wi-Fi/BT module on-board) -40°C ÷ +85°C (Industrial version)

WARRANTY

2 Years
