GPU

R NVIDIA Maxwell™ architecture with 128 NVIDIA CUDA® cores 0.5 TFLOPS (FP16)

CPU

Quad-core ARM® Cortex®-A57 MPCore processor

RAM

4 GB LPDDR41600 MHz – 25.6 GB/s

STORGAE

16 GB eMMC 5.1

VIDEO ENCODING

250 MP/s,1x 4K @ 30 (HEVC),2x 1080p @ 60 (HEVC),4x 1080p @ 30 (HEVC)

VIDEO DECODING

500 MP/s,1x 4K @ 60 (HEVC),2x 4K @ 30 (HEVC),4x 1080p @ 60 (HEVC) 8x 1080p @ 30 (HEVC)

CAMERA

12 lanes (3×4 or 4×2) MIPI CSI-2 D-PHY 1.1 (18 Gbps)

NETWORKING

Wi-Fi requires external chip

DISPLAY

eDP 1.4 | DSI (1 x2) 2 simultaneous, eDP (1920 x 1080), LVDS 1600 x 1200

UPHY

1×1/2/4 PCIE、1 * USB 3.0、3 * USB 2.0

IO

3 * UART、2 * SPI、2 * I2S、4 * I2C, GPIO

HDMI

1

DP

1

USB

4 * USB 3.0 Gen1 ports

ETHERNET

1 * RJ-45 LAN ports

POWER

5V DC-in jack

MODULE CARD HOLDER

1

SD CARD

1

M.2

1*M-key interface

GPIO

40Pin GPIO Expansion Interface

FAN INTERFACE

1* 1.25mm fan Interface, 1 *2.54mm fan interface

POE PIN

1

CAMERA INTERFACE

2-way MIPI CSI camera interface

CERTIFICATIONS

CE, FCC

WARRANTY

1 Year
