PBC-02013
Industrial Fanless Embedded Computer with Intel® SoC Celeron, i3/i5/i7 4th, 5th, 6th, 7th & 8th Gen processor, Dual LAN, Mini PCIe for Wi-Fi
Features :
- Support Celeron, Core i3/i5/i7-4th, 5t, 6th, 7th and 8th gen SoC Processor
- Support up to 64GB RAM
- Support Dual Display VGA & HDMI, Dual LAN, 6-USB
- Support One Mini-PCIe for Wi-fi/4G Module, one M.2 2260/2280 NVMe SSD
- Support 6-COM ports (COM 5, 6 - supports RS232/485 switching)
- 2x Antenna hole for WiFi or 4G/GPS module to use
- Audio Line-out/ Mic-In
Description
The Industrial Fanless Embedded Box-PC PBC-02013 builds on SoC and takes advantages of 4th/5th….8th Generation Intel® Core™ i3/i5/i7 processors. It is rich of I/O having Six USB and Serial Ports, also support one/Two Memory slots, and support 2.5” SSD slots for storage. Support two Gigabit Ethernet ports , One M.2 2260/2280, and one mSATA port up to 6Gbps. The PBC-02013 is an ideal platform with rich I/O and high resolution for Transportation, Toll gateways, digital signage, and factory automation applications.
Specification
| EBC-01008 | |
|---|---|
|
Dimension |
174*148*78mm (L*W*H) |
|
CPU |
Integrated Intel®Skylake-U I5 6300U/2.0GHz dual-core four-thread processor TDP
15W |
|
CHIPSET |
Based on Intel®Skylake-U SOC platform
|
|
RAM |
2*DDR4 SODIMM support 2133MHz MAX 32GB |
|
GRAPHICS |
Integrated Intel® Iris™ Graphics 540 supports DirectX 12 OpenGL 4.4 |
|
HDMI |
1 *HDMI1.4 |
|
VGA |
1 |
|
Multi Display |
Dual Independent Display |
|
ETHERNET |
2*Intel® WGI211AT Gigabit network card, support Wake on LAN, PXE function
|
|
MINI-PCIE |
1* Mini PCIE slot, support WIFI/4G module |
|
M.2 |
1*M.2 slot, support M.2 2260/2280 NVME PCIE standard SSD |
|
SATA |
1 * SATA
|
|
M-SATA |
1 * MSATA SSD solid state drive expansion, transmission speed up to 6Gbps |
|
AUDIO |
1* Line out interface, 1* MIC interface
|
|
USB |
4* USB3.0 interface, 4* USB2.0 interface
|
|
SERIAL PORT |
4* DB9 RS232 serial interface, COM1/2 supports the 9th pin 5V/12V charged
2* DB9 serial interface, COM5, COM6 support RS232/RS485 switch |
|
SWITCH |
1* Power switch, 1* reset switch
|
|
LED |
1*P.LED，1*H.LED |
|
AC LOSS |
1* AC LOSS Electric auto power |
|
SIM |
1* SIM card slot, 3G/4G module |
|
Ps/2 |
1 |
|
GPIO |
1*12pin，support 4-in 4-out GPIO，switch，5V |
|
POWER TYPE |
External Power Adapter |
|
INPUT POWER |
DC 12V voltage input |
|
WATT |
Power output AC TO DC 60W |
|
OPERATING
TEMP |
-10℃～60℃ |
|
STORAGE TEMP |
-20℃～70℃
|
|
CERTIFICATEION |
CE,FCC
|
|
ACESSORIES |
1 * Power adaptor, 1* HDD Clamp, 1 * Phoenix Connector. |
|
WARRANTY |
2 Years |
